Integration into the existing machine infrastructure is now even easier thanks to additional software functions
The additional functions with regard to communication, interfaces and measuring tasks can be activated as a package through the purchase of a licence. These functions are:
- OPC UA (Open Platform Communications Unified Architecture)
- E-mail functionality
- Channel monitoring measuring task
OPC UA communication standard
![OPC UA communication standard](https://www.schaeffler.cn/remotemedien/media/_shared_media_rwd/05_products_services_1/industrial_products_services/mechatronics/mechatronics_new/47678_16_9-schaeffler-products-smartcheck-software-package-opc-ua_rwd_1000.jpg)
Through the integration of OPC UA, SmartCheck and ProLink CMS offer a widely-used, manufacturer-independent communication standard (based on IEC 62541) for industrial communication. It facilitates easy, bidirectional exchange of information between the sensor and a higher level (e.g. with a control system).
Benefits
- Simple integration into the existing infrastructure
- Bidirectional exchange of information (read, write) between the sensor and the controller level
- OPC UA clients tested so far: UaExpert, PTC Kepware, CODESYS, Copadata Zenon, Siemens, Beckhoff TwinCat
E-mail functionality
The e-mail functionality expands the SmartCheck's and ProLink's range of functions by an additional option for data transmission. Sending data and information via e-mail helps companies prevent IT security problems. This provides maintenance technicians with increased flexibility and enables them to react more quickly to changes occurring in the machines.
- The prerequisite for using this functionality is access to an e-mail server in the network.
- Messages and data are sent via a standard communication channel
- Information on the condition of the machines is available wherever and whenever it is needed
![E-mail functionality](https://www.schaeffler.cn/remotemedien/media/_shared_media_rwd/05_products_services_1/industrial_products_services/mechatronics/mechatronics_new/0015AE53_16-9-schaeffler-products-smartcheck-software-package-e-mail-function_rwd_1000.jpg)
Channel monitoring
The channel monitoring measuring task provides the option of continuously monitoring up to three channels (vibrations, temperature, process signals) and immediately sounding an alarm as soon as a limit value is exceeded.
Unlike conventional condition monitoring, channel monitoring makes it possible to view the signal curve before the occurrence of an event (max. 1s).
- Continuous monitoring of parameters
- Immediate detection of sporadically occurring events
- Investigation of the root causes of isolated events
Request a quote for a paid software package now
